Roberts Gordon 90439500K Replacement Part
NOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 90439501K
Includes:
- (1) - Electric Connector Vertical Pin (91322300)
- (1) - Ignition Module Microprocessor (90439500)
- (1) - Ignition Cable 17" (90427706)
- (1) - Ignition Cable RTH-150B/CTH-1 (90434800)
- (1) - Instructions (91700012)
- (2) - Screw #8 - 32 x 3/4 (93911412)
- (2) - Locknut 8 - 32 (92311400)
Specifications
- Manufacturer: Fenwal
- Model Number: 35-605393-337
- Automatic Ignition System
- Pre-Purge: 45 Seconds
- Ignition: 15 Seconds
- Interpurge: 45 Seconds
- Input: 24 VAC, 50/60 Hz, 300 mA
- Valve: 24 VAC, 2.0 A Maximum
- Ambient Temp Range: -40 to 160 Degrees Fahrenheit
Replaces Old Roberts Gordon Part Numbers
- 90434000
- 90434004
Other Part Numbers
Roberts Gordon, 90439500, 90439500K, 35-605939-337, ANSI Z21.20, CAN/CSA-C22.2, 199-M89, Fenwal, 1443CC, 91322300, 90439500, 90427706, 90434800, 93911412, 92311400, 91700012
Fits Models:
(Press ctrl + F to find model number below.)
CTH & CTH-1, RTH-150B, RTH-150A, BH-BlackHeat, CRV-B, CRV-B
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
