Ritter & Bader 940-010-062 Rotary Actuator Motor

Ritter & Bader 940-010-062 Replacement Part

Includes:

• (1) - Rotary Actuator Motor (940-010-062)
• (1) - Shaft Key Handle
• (1) - LRA (LRB) CCV M4+M5 Kit (13131-00001)
• (1) - Instruction Sheet (70741-00001E)
• (1) - Instruction Sheet (71364-00001-A)
• (1) - Part Declaration Sheet (71902-00001.B)
• (1) - Sales Address Sheet (71648-00002.D)

Specifications

• Manufacturer: Belimo
• Model # LR24A
• Voltage: AC 24 V/DC 24 V, 50/60 Hz
• Power supply range AC/DC 19.2 - 28.8 V
• Power Consumption(In Operation): 1 W at Nominal Torque
• Power Consumption(At Rest): 0.2W
• Power Consumption(For Wire Sizing): 2 VA
• Connection: Cable 1 m, 3 x 0.75 mm2
• Parallel connection Possible
• Torque (Nominal Torque): Min. 5 Nm at Nominal Voltage
• Manual Override: Gearing Latch Disengaged with Pushbutton (temporary-permanent)
• Running Time: 90 s / 90°
• Noise Level: Max. 35 dB (A) (Without the Valve)
• Position Indication: Mechanical, Add-On
• Safety Protection

Country of Origin: Switzerland

Replaces Old Ritter & Bader Part Numbers

• There are no older part numbers.

Other Part Numbers

LR24A, 0101, NEMA2 / IP54, Made in Switzerland, 10171, Drive Valve Actuator Motor, 9405, 10171-00001, Stellantrieb fur Regelkugelhahnen

Fits Models:

(Press ctrl + F to find model number below.)

Various. (Call 734-326-3900 with your model and serial number for more information.)
