Ritter & Bader 922-060-085 Electronic Cooling Controller

Ritter & Bader 922-060-085 Replacement Part

Includes:

• (1) - Temperature Controller (922-060-085)
• (1) - Mounting Bracket (-)
• (1) - Rubber Seal (-)

Specifications

• Manufacturer: JUMO GmbH & Co.
• Model # eTRON M100
• Type # 701061/920-32/000
• Display Format: 3-Digit Backlit LCD Display w/ Special Characters
• Display Size: 76mm x 36mm
• 2 Measuring Inputs for RTD Temperature Probes (PT100, PT1000, KTY)
• 1 Binary Input
• 2 x 16a Relays (Changeover Contact) & 1 x 8A Relay (Normally Open Contact)
• Cooling Mode with Electrical or Hot Gas Defrosting Process
• Counters for Operating Hours and Service
• Real-Time Clock, Data Logger and RS485 Interface
• HACCP-Conform Data Recording of the Measuring Inputs and Switching Statuses
• Supply Voltage: 12-24AC/DC
• Supply Hertz: 48-63
• VA: 3

Replaces Old Ritter & Bader Part Numbers

• There are no older part numbers.

Other Part Numbers

922060085, 05131298, Temperaturregler, eTRON M100 PID, VART-NR: 70/00502412, 701, 00502412, 0249238601018200023, RS485,

Fits Models:

(Press ctrl + F to find model number below.)

Various. (Call 734-326-3900 with your model and serial number for more information.)
