Mueller Industries A16646 Replacement Part
Includes:
- (1) - Filter Drier (A16646)
- (1) - Instructions (
Specifications
- Manufacturer: Mueller Industries
- Model # SD-052
- Series: Drymaster Plus
- Flow: Uni-Flow
- Core: Solid Core, 80% Molecular Sieve, 20% Activated Alumina
- Filtration: High Retention Filter Down to 25 Microns
- Volume: 5 in³
- Approved Media: CFC/HFC/HCFC & HFO
- Connection Size: 1/4" Solder
- Design Pressure: 700 psig (48 bar)
- Max Abnormal Pressure: 833 psig (57 bar)
- Continuous Operating Temperature: -40°C to 71°C (-40°F to 160°F)
- Length: 4 2/5"
- Circumference: 7 1/2"
Country of Origin: Mexico
Replaces Old Mueller Industries Part Numbers
- There are no older part numbers.
Other Part Numbers
Mueller, A 16646, SD-052, Micro-Guard filter Drier, 5 CU. Inch, 1/4 Solder,. Dry Master Plus, Filter Drier
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
