Lochinvar RLY1131 Replacement Part
NOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 100208513
Includes:
- (1) - Control Board (S8610U3009)
- (1) - Spade Connector (-)
- (1) - Terminal Nut to Spade Connector (-)
- (3) - Black Wire Nut (-)
- (1) - Sticker Sheet (-)
- (1) - Status LED Sticker (-)
- (1) - Timing Select Settings Sticker (-)
- (1) - Installation Instructions (69-1955-02)
Specifications
- Manufacturer: Honeywell
- Manufacturer Part # S8610U3009
- Gas Type: Natural or LP
- Control Voltage: 24 VAC (18-30 VAC), 50/60 Hz
- Anticipator Setting: 0.1A Plus Valve Load @ 24 VAC
- Pilot Valve MAX Amperage: 1.0 A
- Main Valve MAX Amperage: 2.0 A
- Pre-Purge Timing: 0 or 30 Seconds (Field Selectable)
- Trial for Pilot Ignition: 15 or 90 Seconds (Field Selectable)
- Ignition Sequence Type: Retry
- Flame Failure Response Time: 2 Seconds Max
- Operating Temperature: -40 to 165 Degrees Fahrenheit When Used With 2.0 A Main Valve
- Relative Humidity: 0-95% Non-Condensing
- Board Dimensions:
- Length: 5 1/4"
- Width: 4"
- Depth: 2"
Replaces Old Lochinvar Part Numbers
- There are no older part numbers.
Other Part Numbers
IGN. Module, SP845, P5A5, SPARK Sense, 50043738-001, 1208J41944, CNR/CLR 125-75 thru 501-080, RLY2900, RLY2900K
Fits Models:
(Press ctrl + F to find model number below.)
Charger (CNR/CLR 125-75 thru 501-080), Charger (CNR/CLR 625-080 thru 726-080)
- SKU:
- RLY1131
- Condition:
- New
- Weight:
- 2.00 LBS
- Replaced by Part #:
- 100208513
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
