Lennox 91M02 Replacement Part
NOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 12J20
Note: If replacement parts are necessary, refer to Lennox part number 69J46. The kit includes 10 brass nuts, 20 teflon rings, 10 liquid line orifices and 10 liquid line assemblies.
Includes:
- (1) - Thermal Expansion Valve
- (1) - Sensing Bulb Mounting Plate
- (2) - Hex Head Machine Screws
- (2) - Square Nuts
- (2) - Teflon Rings
- (1) - Instructions (505,350M)
Specifications
- Manufacturer: Parker
- Model: HCE
- Refrigerant: R410A
- Sensing capillary Tube Length: 30"
- In: FLWRTR
- Out: FLWRTR
- Ext: 1/4" Flare
- Capacity: 3.5-6 Ton
- Charge/MOP: KX200
Replaces Old Lennox Part Numbers
- 100188-02
Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:
- 100188-02
Other Part Numbers
M43041536013, 041247-02, 22314AMX, 247-02,, CTN-0502
Fits Models:
(Press ctrl + F to find model number below.)
BCS3M48-1, BCS3M48-AF, BCS3M60-1, BCS3M48C00NA1P-1, BCS3M60C00NA1P-1, CB26UH-048-1, CB26UH-048-230-1, CB26UH-048-R-1, CB26UH-048-R-230-1, CB26UH-060-1, CB26UH-060-230-1, CB26UH-060-R-1, CB26UH-060-R-230-1-1, CBX25UH-048-1, CBX25UH-060-1, CBX25UHV-048-1, CBX25UHV-060-1, CBX26UH-048-1, CBX26UH-048-2, CBX26UH-048-230-1, CBX26UH-048-230-2, CBX26UH-060-1, CBX26UH-060-2, CBX26UH-060-230-1, CBX26UH-060-230-2, CBX27UH-042-230-01, CBX27UH-042-230-02, CBX27UH-042-230-03, CBX27UH-048-230-01, CBX27UH-048-230-02, CBX27UH-048-230-03, CBX27UH-048-460-01, CBX27UH-060-230-01, CBX27UH-060-230-02, CBX27UH-060-230-03, CBX27UH-060-460-01, CBX27UH-060-460-02, CBX32M-042-230-6-04, CBX32M-042-230-6-05, CBX32M-048-230-6-04, CBX32M-048-230-6-05, CBX32M-048-460-6-05, CBX32M-060-230-6-04, CBX32M-060-230-6-05, CBX32M-060-460-6-05, CBX32MV-048-230-6-03, CBX32MV-048-230-6-05, CBX32MV-048-230-6-06, CBX32MV-060-230-6-03, CBX32MV-060-230-6-05, CBX32MV-060-230-6-06, CBX32MV-068-230-6-03, CBX32MV-068-230-6-05, CBX32MV-068-230-6-06, CBX32MV-068-230-6-07, CBX40UHV-042-230-6-01, CBX40UHV-042-230-6-02, CBX40UHV-042-230-6-03, CBX40UHV-048-230-6-01, CBX40UHV-048-230-6-02, CBX40UHV-048-230-6-03, CBX40UHV-060-230-6-01, CBX40UHV-060-230-6-02, CBX40UHV-060-230-6-03, CX34-49C-6F-1, CX34-50/60C-6F-1, CX34-60D-6F-1, CX34-62C-6F-1, CX34-62D-6F-1, RBCS2M48-1, RBCS2M60-1, RBCS3M48C00NA1P-1, RBCS3M60C00NA1P-1
Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:
(Press ctrl + F to find model number.)
ACBX32CM-148-230-6-1, ACBX32CM-148-460-6-1, ACBX32CM-160-230-6-1, ACBX32CM-160-460-6-1
- SKU:
- 91M02
- Condition:
- New
- Weight:
- 2.00 LBS
- Replaced by Part #:
- 12J20
