Lennox 36W90 Limit Switch

No reviews yet Write a Review
$63.38
Brand
Lennox
SKU:
36W90
Condition:
New
Weight:
1.00 LBS
Shipping:
Calculated at Checkout
Cut-In Temp:
160
Cut-Out Temp:
190
  • Technical Hot & Cold BBB Business Review

Lennox 36W90 Limit Switch

$63.38
  • Part Info & Specifications

  • Lennox 36W90 Replacement Part

    Includes:

    • (1) - Limit Switch (36W90)

    Specifications

    • Normall Closed
    • Opens on Temperature Rise @ 190°F
    • Closes on Temperature Drop @ 160°F
    • Element Length: 3"

    Replaces Old Lennox Part Numbers

    • R46105-007

    Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:

    • R46105-007

    Other Part Numbers

    46105-007, 1449183805, 36T01B3, 44935, A1449, 6255138143, 1PR46105-007, 1P36W90

    Fits Models:

    (Press ctrl + F to find model number below.)

    12GCS048-125-6P, 12GCS048X-125-6P, CG80TB075D12AL-1, CG80TB075D12AL-2, CG80TB100D20CL-1, CG80TB100D20CL-2, CG80TB125D20C-1, CG80TB125D20C-2, CG90UB125D20D-1

    Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:

    (Press ctrl + F to find model number.)

    26HWC123A-2, 26HWC123HA-2, 26HWC123LA-2, 26HWC123NA-2, 26HWC123SA-2, 26HWC124A-1, 26HWC124A-2, 26HWC124HA-1, 26HWC124HA-2, 26HWC124LA-2, 26HWC124NA-1, 26HWC124NA-2, 26HWC124SA-1, 26HWC4-09-121HP-1, 26HWC4-09-121HP-2, 26HWC4-09-121LP-1, 26HWC4-09-121NP-1, 26HWC4-09-121NP-2, 26HWC4-09-121P-1, 26HWC4-09-121P-2, 38HWC123A-2, 38HWC123HA-2, 38HWC123LA-2, 38HWC123NA-2, 38HWC123SA-2, 38HWC124A-2, 38HWC124HA-1, 38HWC124HA-2, 38HWC124LA-2, 38HWC124NA-1, 38HWC124NA-2, 38HWC124SA-1, 38HWC183A-3, 38HWC183HA-3, 38HWC183LA-3, 38HWC183NA-3, 38HWC183SA-3, 38HWC184A-1, 38HWC184A-2, 38HWC184HA-1, 38HWC184HA-2, 38HWC184LA-1, 38HWC184LA-2, 38HWC184NA-1, 38HWC184NA-2, 38HWC184SA-1, 38HWC243A-2, 38HWC243HA-2, 38HWC243LA-2, 38HWC243NA-2, 38HWC243SA-2, 38HWC244A-2, 38HWC244HA-1, 38HWC244HA-2, 38HWC244LA-2, 38HWC244NA-1, 38HWC244NA-2, 38HWC244SA-1, 38HWC4-09-121HP-1, 38HWC4-09-121HP-2, 38HWC4-09-121LP-1, 38HWC4-09-121NP-1, 38HWC4-09-121NP-2, 38HWC4-09-121P-1, 38HWC4-09-121P-2, 38HWC4-09-181HP-1, 38HWC4-09-181HP-2, 38HWC4-09-181LP-1, 38HWC4-09-181NP-1, 38HWC4-09-181NP-2, 38HWC4-09-181P-1, 38HWC4-09-181P-2, 38HWC4-09-241HP-1, 38HWC4-09-241HP-2, 38HWC4-09-241LP-1, 38HWC4-09-241NP-1, 38HWC4-09-241NP-2, 38HWC4-09-241P-1, 38HWC4-09-241P-2, 51HWC183A-3, 51HWC183HA-3, 51HWC183LA-3, 51HWC183NA-3, 51HWC183SA-3, 51HWC184A-1, 51HWC184A-2, 51HWC184HA-1, 51HWC184HA-2, 51HWC184LA-1, 51HWC184LA-2, 51HWC184NA-1, 51HWC184NA-2, 51HWC184SA-1, 51HWC243A-2, 51HWC243HA-2, 51HWC243LA-2, 51HWC243NA-2, 51HWC243SA-2, 51HWC244A-2, 51HWC244HA-1, 51HWC244HA-2, 51HWC244LA-2, 51HWC244NA-1, 51HWC244NA-2, 51HWC244SA-1, 51HWC303A-2, 51HWC303F-2, 51HWC303HA-2, 51HWC303LA-2, 51HWC303NA-2, 51HWC303SA-2, 51HWC304A-1, 51HWC304HA-1, 51HWC304LA-1, 51HWC304NA-1, 51HWC4-09-181HP-1, 51HWC4-09-181HP-2, 51HWC4-09-181LP-1, 51HWC4-09-181NP-1, 51HWC4-09-181NP-2, 51HWC4-09-181P-1, 51HWC4-09-181P-2, 51HWC4-09-241HP-1, 51HWC4-09-241HP-2, 51HWC4-09-241LP-1, 51HWC4-09-241NP-1, 51HWC4-09-241NP-2, 51HWC4-09-241P-1, 51HWC4-09-241P-2, 51HWC4-09-301HP-1, 51HWC4-09-301LP-1, 51HWC4-09-301NP-1, 51HWC4-09-301P-1, 64HWC183A-3, 64HWC183HA-3, 64HWC183LA-3, 64HWC183NA-3, 64HWC183SA-3, 64HWC184A-1, 64HWC184A-2, 64HWC184HA-1, 64HWC184HA-2, 64HWC184LA-1, 64HWC184LA-2, 64HWC184NA-1, 64HWC184NA-2, 64HWC184SA-1, 64HWC243A-2, 64HWC243HA-2, 64HWC243LA-2, 64HWC243NA-2, 64HWC243SA-2, 64HWC244A-2, 64HWC244HA-1, 64HWC244HA-2, 64HWC244LA-2, 64HWC244NA-1, 64HWC244NA-2, 64HWC244SA-1, 64HWC303A-2, 64HWC303HA-2, 64HWC303LA-2, 64HWC303NA-2, 64HWC303SA-2, 64HWC304A-1, 64HWC304HA-1, 64HWC304LA-1, 64HWC304NA-1, 64HWC4-09-181HP-1, 64HWC4-09-181HP-2, 64HWC4-09-181LP-1, 64HWC4-09-181NP-1, 64HWC4-09-181NP-2, 64HWC4-09-181P-1, 64HWC4-09-181P-2, 64HWC4-09-241HP-1, 64HWC4-09-241HP-2, 64HWC4-09-241LP-1, 64HWC4-09-241NP-1, 64HWC4-09-241NP-2, 64HWC4-09-241P-1, 64HWC4-09-241P-2, 64HWC4-09-301HP-1, 64HWC4-09-301LP-1, 64HWC4-09-301NP-1, 64HWC4-09-301P-1, CG80TA075D12A-2, CG80TA075D12AL-2, CG80TA100D20C-2, CG80TA100D20CL-2, CG80TA125D20C-2, CG80TA125D20CL-2, CG80TB075D12A-1, CG80TB075D12A-2, CG80TB075D12AL-1, CG80TB075D12AL-2, CG80TB100D20C-1, CG80TB100D20C-2, CG80TB100D20CL-1, CG80TB100D20CL-2, CG80TB125D20C-1, CG80TB125D20C-2, CG80TB125D20CL-1, CG80TB125D20CL-2, CG80TC125V20C-1, CG80TC125V20CL-1, CG80UA075D12A-1, CG80UA075D12A-2, CG80UA075D12AL-1, CG80UA075D12AL-2, CG80UA100D20C-1, CG80UA100D20C-2, CG80UA100D20CL-1, CG80UA100D20CL-2, CG80UA125D20C-1, CG80UA125D20C-2, CG80UA125D20CL-1, CG80UA125D20CL-2, CG80UB075D12A-1, CG80UB075D12A-2, CG80UB075D12AL-1, CG80UB075D12AL-2, CG80UB100D20C-1, CG80UB100D20C-2, CG80UB100D20CL-1, CG80UB100D20CL-2, CG80UB125D20C-1, CG80UB125D20C-2, CG80UB125D20CL-1, CG80UB125D20CL-2, CG90CB112D20D-1, CG90UB125D20D-1, CG95UC125V20D-1, G1D80AT100D14B-2, G1D80AT100D14BL-2, G1D80BT100D14B-1, G1D80BT100D14B-2, G1D80BT100D14B-3, G1D80BT100D14BL-1, G1D80BT100D14BL-2, G1D80BT100D14BL-3, G1D93BC112D20D-1, G1D93BC112D20D-2, G1N80AT075D12A-2, G1N80AT075D12AL-1, G1N80AT075D12AL-2, G1N80AT100D20C-2, G1N80AT100D20CL-1, G1N80AT100D20CL-2, G1N80AT100D22C-1, G1N80AT100D22C-2, G1N80AT100D22CL-1, G1N80AT100D22CL-2, G1N80AT125D20C-2, G1N80AT125D20CL-1, G1N80AT125D20CL-2, G1N80AU075D12A-1, G1N80AU075D12A-2, G1N80AU075D12AL-1, G1N80AU075D12AL-2, G1N80AU100D20C-1, G1N80AU100D20C-2, G1N80AU100D20CL-1, G1N80AU100D20CL-2, G1N80AU125D20C-1, G1N80AU125D20C-2, G1N80AU125D20CL-1, G1N80AU125D20CL-2, G1N80BT075D12A-1, G1N80BT075D12A-2, G1N80BT075D12A-3, G1N80BT075D12AL-1, G1N80BT075D12AL-2, G1N80BT075D12AL-3, G1N80BT100D20C-1, G1N80BT100D20C-2, G1N80BT100D20C-3, G1N80BT100D20CL-1, G1N80BT100D20CL-2, G1N80BT100D20CL-3, G1N80BT100D22C-1, G1N80BT100D22C-2, G1N80BT100D22C-3, G1N80BT100D22CL-1, G1N80BT100D22CL-2, G1N80BT100D22CL-3, G1N80BT125D20C-1, G1N80BT125D20C-2, G1N80BT125D20C-3, G1N80BT125D20CL-1, G1N80BT125D20CL-2, G1N80BT125D20CL-3, G1N80BU075D12A-1, G1N80BU075D12A-2, G1N80BU075D12A-3, G1N80BU075D12AL-1, G1N80BU075D12AL-2, G1N80BU075D12AL-3, G1N80BU100D20C-1, G1N80BU100D20C-2, G1N80BU100D20C-3, G1N80BU100D20CL-1, G1N80BU100D20CL-2, G1N80BU100D20CL-3, G1N80BU125D20C-1, G1N80BU125D20C-2, G1N80BU125D20C-3, G1N80BU125D20CL-1, G1N80BU125D20CL-2, G1N80BU125D20CL-3, G2D80AT125V20C-1, G2D80AT125V20C-2, G2D80BT125V20C-1, G2D80BT125V20CL-1, G2D80CT125V20C-1, G2D80CT125V20C-2, G2D80CT125V20C-3, G2D80CT125V20CL-1, G2D80CT125V20CL-2, G2D80CT125V20CL-3, G2D95BU125V20D-1, G2D95CU125V20D-1, G2D95CU125V20D-2, PGE10B36D100A-3, PGE10B36D100A-9, PGE10B36D100LA-3, PGE10B36D100LA-9, PGE10C36D100B-6, PGE10C36D100B-9, PGE10C36D100LB-6, PGE10C36D100LB-9, PGE12B36D100A-3, PGE12B36D100A-9, PGE12B42D075LA-3, PGE12B42D075LA-9, PGE12B48D125A-4, PGE12B48D125A-9, PGE12B48D125LA-4, PGE12B48D125LA-9, PGE12B60D125A-4, PGE12B60D125A-9, PGE12B60D125LA-4, PGE12B60D125LA-9, RPG10B36D100A-8, RPG10B36D100A-9, RPG10B36D100LA-8, RPG10B36D100LA-9, RPG10C36D100B-8, RPG10C36D100B-9, RPG10C36D100LB-8, RPG10C36D100LB-9, RPG12B36D100A-5, RPG12B36D100A-9, RPG12B48D125A-5, RPG12B48D125A-9, RPG12B48D125LA-5, RPG12B48D125LA-9, RPG12B60D125A-5, RPG12B60D125A-9, RPG12B60D125LA-5, RPG12B60D125LA-9, WFAT075A12-1A, WFAT075A12-1B, WFAT075A12-2, WFAT100C20-1A, WFAT100C20-1B, WFAT100C20-2, WFAT125C20-1A, WFAT125C20-1B, WFAT125C20-2, WFAU075A12-1A, WFAU075A12-1B, WFAU075A12-2, WFAU100C20-1A, WFAU100C20-1B, WFAU100C20-2, WFAU125C20-1A, WFAU125C20-1B, WFAU125C20-2, WFCC112D20-1, WFCC112D20-1B, WFCU125D20-1, WFCU125D20-1B, WFLT075A12-1A, WFLT075A12-1B, WFLT075A12-2, WFLT100C20-1A, WFLT100C20-1B, WFLT100C20-2, WFLT125C20-1A, WFLT125C20-1B, WFLT125C20-2, WFLU075A12-1A, WFLU075A12-1B, WFLU075A12-2, WFLU100C20-1A, WFLU100C20-1B, WFLU100C20-2, WFLU125C20-1A, WFLU125C20-1B, WFLU125C20-2, WGFBLT125C20-1, WGFBLT125C20-1A, WGFBLT125C20-1B, WGFBLT125C20-2A, WGFBLT125C20-3C, WGFBT125C20-1, WGFBT125C20-1A, WGFBT125C20-1B, WGFBT125C20-2A, WGFBT125C20-3C, WGFDC112D20-1A, WGFDC112D20-1C, WGFEU125D20-1A
