Lennox 23L53 Ignition Control Board

Lennox 23L53 Replacement Part

Includes:

• (1) - Ignition Control Board (23L53)

Specifications

• Automatic Ignition System
• Voltage: 24
• Hertz: 50/60
• Amperage: 0.5 Max
• Fuse: 3 Amp
• Board Dimensions (LxW): 5 3/4" x 4 1/2"

Replaces Old Lennox Part Numbers

• 96M50
• 23L5301

Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:

• 65312200
• R76722700
• 20516602
• 23L5301

Other Part Numbers

1097-83-503A, ANSI Z21.20, 1407, 065312200, 65312200, 1097-83-5051A, TROV000291288, 1097-504-I. 3918M098852

Fits Models:

(Press ctrl + F to find model number below.)

LD24-100-3, LD24-100A-3, LD24-100S-3, LD24-125-3, LD24-125A-3, LD24-125S-3, LD24-150-3, LD24-150A-3, LD24-150S-3, LD24-200-3, LD24-200A-3, LD24-200S-3, LD24-250-3, LD24-250A-3, LD24-250S-3, LD24-300-3, LD24-300A-3, LD24-300S-3, LD24-75-3, LD24-75A-3, LD24-75S-3, LF24-100A-5, LF24-100A-P4, LF24-100S-5, LF24-100S-P4, LF24-115A-1, LF24-115A-5, LF24-115S-1, LF24-115S-5, LF24-125A-5, LF24-125A-P4, LF24-125S-5, LF24-125S-P4, LF24-145A-1, LF24-145A-5, LF24-145S-1, LF24-145S-5, LF24-150A-5, LF24-150A-P4, LF24-150S-5, LF24-150S-P4, LF24-175A-1, LF24-175A-5, LF24-175S-1, LF24-175S-5, LF24-200A-6, LF24-200A-P5, LF24-200S-6, LF24-200S-P5, LF24-230A-1, LF24-230A-5, LF24-230S-1, LF24-230S-5, LF24-250A-5, LF24-250A-P4, LF24-250S-5, LF24-250S-P4, LF24-300A-5, LF24-300A-P4, LF24-300S-5, LF24-300S-P4, LF24-30A-5, LF24-345A-5, LF24-345A-P5, LF24-345S-5, LF24-345S-P5, LF24-400A-5, LF24-400A-P5, LF24-400S-5, LF24-400S-P5, LF24-45A-5, LF24-60A-2, LF24-75A-5, TUA045SNAF-1

Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:

(Press ctrl + F to find model number.)
