Lennox 11H36 Control Board Kit
click to zoom in

Have Questions? Ask a Tech!

(734) 326-3900 Talk to a Technician

  • Genuine OEM Parts

    Offering genuine parts for your specific brand.

  • In-House HVAC Techs

    We help you diagnose, find, and install the part.

  • 1-Year Warranty & Returns

    Failed, or didn't need it? No hassle returns.

  • Expedited Delivery

    Offering competitively-priced expedited shipping.

Lennox 11H36 Control Board Kit

No reviews yet Write a Review
$427.66
Brand
Lennox
SKU:
11H36
Condition:
New
Weight:
4.00 LBS
Shipping:
Calculated at Checkout
  • Technical Hot & Cold BBB Business Review

Lennox 11H36 Control Board Kit

$427.66

video gallery

  • Part Info & Specifications

    • Description

    Lennox 11H36 Replacement Part

    Includes:

    • (1) - Control Board (103369-04)
    • (1) - Compressor Solenoid Harness (49M7301)
    • (7) - #10-32x1/2" Hex Slotted Washer Head Self Tap Screws (P-*8-3981)
    • (5) - Wire Wraps (100082-02)
    • (1) - Heat Pump Outdoor Units XP17 Sticker (537508-01)
    • (1) - Heat Pump Outdoor Units XP17N Sticker (537565-01)
    • (1) - Heat Pump Outdoor Units XP19-06 Sticker (537514-01)
    • (1) - Heat Pump Outdoor Units Sticker (XP21)
    • (1) - Heat Pump Outdoor Units XP21N Sticker (537566-01)
    • (1) - Cooling Condensing XC17 Sticker (537507-01)
    • (1) - Cooling Condensing XC21 Sticker (537509-01)
    • (1) - Cooling Condensing XC21-04 Sticker (537509-01)
    • (1) - Heat Pump Outdoor Units Sticker XP21 Sticker (537510-01)
    • (1) - Outdoor Unit Jumper & Link Guide (580657-01)
    • (1) - 7 Segment Display & Configuration Guide (580656-01)
    • (1) - Installation Instructions (507344-01)

    Specifications

    • Solenoid Input Voltage: 24v AC/DC
    • Solenoid Output Voltage: 24DC
    • Rectifier Inside Solenoid
    • Solenoid Lead: 2
    • Solenoid Lead Length: 36"
    • Board Dimensions (LxW): 6 3/8" x 4 1/2"

    Replaces Old Lennox Part Numbers

    • 10T56
    • 90W83
    • 605341-10
    • 605341-09
    • 103369-03
    • 609324-01
    • 16X41
    • 96W57

    Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:

    • 605341-10

    Other Part Numbers

    Lennox, icomfort control kit, 1184-501, 103369-04, 00AD5BB4, 1810-013051M, 2.6, 1184-83-501 REV.A, 03C111320005HA, 49m7301, 234194, 04-11-18

    Fits Models:

    (Press ctrl + F to find model number below.)

    SL18XC1-024-230A-01, SL18XC1-030-230A-01, SL18XC1-036-230A-01, SL18XC1-042-230A-01, SL18XC1-048-230A-01, SL18XC1-060-230A-01, SL18XP1-024-230A-01, SL18XP1-030-230A-01, SL18XP1-036-230A-01, SL18XP1-042-230A-01, SL18XP1-048-230A-01, SL18XP1-060-230A-01, XC17-030-230-09, XC21-024-230-09, XC21-036-230-09, XC21-048-230-09, XC21-060-230-10, XP17-024-230-09, XP17-030-230-09, XP17-030-230-10, XP17-030-230-11, XP17-042-230-09, XP17-048-230-09, XP21-024-230-07, XP21-036-230-06, XP21-048-230-06, XP21-060-230-06

    Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:

    (Press ctrl + F to find model number.)

    SL18XC1-024-230A-01, SL18XC1-030-230A-01, SL18XC1-036-230A-01, SL18XC1-042-230A-01, SL18XC1-048-230A-01, SL18XC1-060-230A-01, SL18XP1-024-230A-01, SL18XP1-024-230A-02, SL18XP1-030-230A-01, SL18XP1-030-230A-02, SL18XP1-036-230A-01, SL18XP1-036-230A-02, SL18XP1-042-230A-01, SL18XP1-042-230A-02, SL18XP1-048-230A-01, SL18XP1-048-230A-02, SL18XP1-060-230A-01, SL18XP1-060-230A-02, XC17-030-230-09, XP17-024-230-09, XP17-030-230-09, XP17-030-230-10, XP17-030-230-11, XP17-042-230-09, XP17-048-230-09, XP21-024-230-07, XP21-036-230-06, XP21-048-230-06, XP21-060-230-06
