Lennox 10J58 Ignition Control Module

Lennox 10J58 Replacement Part

Includes:

• (1) - Ignition Control Module (35-615908-223)
• (1) - Instructions (06-235580-003 REV AC)

Specifications

• Manufacturer: Fenwal
• Model # 35-615908-223
• Automatic Ignition System
• Pre-Pruge: 30 Seconds, Ignition: 7 Seconds
• Interpurge: 30 Seconds
• Input: 24 VAC, 50/60 Hz 300 mA
• Valve: 24 VAC, 2.0 A max.
• Inducer: 120 VAC, 3.0 A or 240 VAC, 1.5 A, 1/7 HP
• Ambient: -40 to 160° F
• Board Dimensions:
• Length: 5 5/8"
• Width: 4"
• Depth: 2"

Note: Will Replace: ADP 100000240 Ignition Module.Will work on ADP Units: SEP-60A-1.

Replaces Old Lennox Part Numbers

• T6-2102

Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:

• T6-2102

Other Part Numbers

0945CB, ANSI Z21.20, CAN/CSA-C22.2, 199-M89, T6-2102, 862551122602, 110112, 35615908223, Will replace part numbers: 05-299013-263, Fenwal, Ignition, 05299013263, 05-29DIS

Fits Models:

(Press ctrl + F to find model number below.)

LD24-100-1, LD24-100A-1, LD24-100S-1, LD24-125-1, LD24-125A-1, LD24-125S-1, LD24-150-1, LD24-150A-1, LD24-150S-1, LD24-200-1, LD24-200A-1, LD24-200S-1, LD24-250-1, LD24-250A-1, LD24-250S-1, LD24-300-1, LD24-300A-1, LD24-300S-1, LD24-75-1, LD24-75A-1, LD24-75S-1, LF24-100A-1, LF24-100S-1, LF24-125A-1, LF24-125S-1, LF24-150A-1, LF24-150S-1, LF24-200A-1, LF24-200S-1, LF24-250A-1, LF24-250S-1, LF24-300A-1, LF24-300S-1, LF24-50A-1, LF24-50S-1, LF24-75A-1, LF24-75S-1

Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:

(Press ctrl + F to find model number.)
