ICP 1160176 Replacement Part
Note: This Kit is Used to Replace the Hamilton Standard Ignition System.
Includes:
- (1) - Ignition Module (1005651)
- (1) - Pilot Assembly (1160280)
- (1) - Envelope Assembly (390686-36)
- (1) - Electrical Accessory Bag (50019481-001)
- (3) - Wire Tie (711212)
- (1) - Kit Installation Instructions (-)
- (1) - S8610U Installation Instructions (English) (-)
- (1) - S8610U Installation Instructions (French) (-)
- (1) - Electrical Diagram (1006042-B)
- (1) - S8610U Status LED Sticker (-)
- (1) - Single-Rod Pilot Burner/Ignitor Sensor Installation Instructions (69-0984-07)
Specifications
- Manufacturer: Honeywell
- Manufacturer Part #: S8610U3009
- Voltage: 24
- Hertz: 60
- Amps: 1
- Height: 2"
- Length: 5"
- Width: 3 1/4"
- Ignitor Model # Q3451B1715
Country of Origin: USA
Replaces Old ICP Part Numbers
- 1005962
- 1005965
- 1006016
Other Part Numbers
1160176, FASTPARTS IGNITION UPGRADE, S8610U3009, Fast Parts Division, Smyrna, TN US, International Comfort Products, 164 Honeywell, 1925, HQ1160280HW, Q3451B1715, 1925, S8610U Continuous Retry, 50043768-001 Rev. A, US Patent 7721972, 8300381, 8310801, Honeywell 2006
Fits ICP, Heil, Tempstar, Arcoaire, Comfortmaker, Snyder General, KeepRite and Day & Night Models:
(Press ctrl + F to find model number below.)
867.769437, 867.769445, 867.769487, 867.769495, NUGK100DH08, NUGK100KH08, NUGK125DK06, NUGK125KK06,
- SKU:
- 1160176
- Condition:
- New
- Weight:
- 6.00 LBS
- Shipping:
- Calculated at Checkout
- Voltage:
- 24
- Amps:
- 1
