Honeywell L8148J1009 Aquastat Relay

Honeywell L8148J1009 Replacement Part

Includes:

• (1) - Aquastat Relay (L8148J1009)
• (1) - Heat Conductive Compound (-)
• (1) - Tab Terminal (-)
• (1) - Installation Instructions (English) (95-6940-12)
• (1) - Installation Instructions (French) (95-6940F-12)
• (1) - Heat Conductive Compound MSDS Sheet (69-0955-1)

Specifications

• Description: High Limit Aquastat Relay with 15 F fixed differential
• Application : High Limit
• Operating Range, High Limit (F) : 180 F to 240 F
• Operating Range, High Limit (C) : 100 C to 133 C
• Differential Temperature (F) : 15 F fixed
• Switching Action : SPST: High Limit & Circulator
• Anticipator Setting :0.2 A
• Maximum Operating Pressure (psi) : Immersion Well: 255 psi
• Maximum Operating Pressure (kPa) : Immersion Well: 1757 kPa
• Electrical Ratings (ALR) : 44.4A @ 120 Vac
• Electrical Ratings (ALR) : 22.2A @ 240 Vac
• Electrical Ratings : 0.25 A @ 0.25 to 12 Vdc
• Electrical Ratings (burner AFL) : Line Voltage: 7.4 A @ 120 Vac; 3.7 A @ 240 Vac
• Electrical Ratings (burner AFL) : Low Voltage: 0.8 A max. @ 24 Vac
• Electrical Ratings (burner ALR) : Line Voltage: 44.4 A @ 120 Vac; 22.7 A @ 240 Vac
• Electrical Ratings (burner millivolt) : 0.25 A @ 1/4 to 12 Vdc
• Electrical Ratings (circulator AFL) :3.7 A @ 240 Vac
• Electrical Ratings (circulator AFL) :7.4 A @ 120 Vac
• Electrical Ratings (circulator ALR) :44.4 A @ 120 Vac
• Electrical Ratings (circulator ALR) :22.7 A @ 240 Vac
• Voltage :120 Vac
• Frequency :60 Hz
• Capillary Length (in.) :4 1/2 in.
• Capillary Length (mm) :114 mm
• Dimensions (in.) :6 1/8 in. high x 4 5/16 in. wide x 3 1/8 in. deep
• Dimensions (mm) :156 mm high x 110 mm wide x 79 mm deep
• Insulation Depth (in.) :1 1/2 in. to 3 in. less well.
• Insulation Depth (mm) :38 mm to 76 mm less well
• Mounting :Vertical or Horizontal Mount
• Operating Humidity Range (% RH) :0 to 95% RH, non-condensing
• Maximum Ambient Temperature (F) :150 F with 1.2 A 24 V load; 77 F with 1.4 A 24 V load
• Maximum Ambient Temperature (C) :66 C with 1.2 A 24 V load; 25 C with 1.4 A 24 V load
• Electrical Connections :Quick-Connect / Screw
• Approvals, Underwriters Laboratories Inc :UL Listed: File No. MP466, Vol. 13, Sec. 2, Guide No. MBPR2.
• Approvals, Canadian Standards Association : Certified: File No. LR95329-1
• Includes :Molex+ plug for use with vent damper, includes heat-conductive compound.

Replaces Old Honeywell Part Numbers

• There are no older part numbers.

Other Part Numbers

L8148J 1009, Aquastat Relay, Honeywell, Tradeline, Relay, Automation and Control Solutions, 97-4785AQ, 1804,

Fits Models:

(Press ctrl + F to find model number below.)

Various. (Call 734-326-3900 with your model and serial number for more information.)
