Honeywell L8148E1281/B Aquastat

Honeywell L8148E1281/B Replacement Part

Includes:

• (1) - Aquastat (L8148E1281/B)
• (1) - Instructions (95-6933-11)

Specifications

• Manufacturer: Honeywell
• Model # L8148E1281/B
• Operating Temperature Range: 140°F to 240°F (60°C to 116°C)
• Differential: Non-Adjustable; Fixed @ 15°F
• Max Ambient Temperature: 150°F with 1.2A, 24V Load;
• 77°F with 1.4A, 24V Load
• Maximum Bulb Temperature: 40° F Over Setpoint, Up to 265°F
• Maximum Pressure on Immersion Well : 255 psi (1757 kPa)
• Max Thermostat Heat Anticipator Setting: 0.2 Amps
• Operating Humidity Range: 0-95% RH, Non-Condensing
• Mounting: Vertical
• VOLTAGE: 120
• Hertz: 60
• Full Load Amperage: 7.4
• Locked Rotor Amperage: 44.4
• VOLTAGE: 240
• Hertz: 60
• Full Load Amperage: 3.7
• Locked Rotor Amperage: 22.7

Replaces Old Honeywell Part Numbers

• There are no older part numbers.

Other Part Numbers

L8148E1281, Aquastat Relay, Replcament Components Division, Factory Authroized Parts, Carrier Corporation, L/5, Honeywell, 97-3139 REV.D, L8148R, 1547

Fits Models:

(Press ctrl + F to find model number below.)

Various. (Call 734-326-3900 with your model and serial number for more information.)
