Fuji Electric 4NC0A0B10Y Replacement Part
NOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 4NC0A0B10
Includes:
- (1) - Magnetic Contactor w/ Auxillary Contact (4NC0A0B10Y)
- (1) - Instruction Manual (INA-F0063g-JEC)
Specifications
- Product Line: Orange
- Operation: AC Coil
- Non-Reversing
- Switch Configuration: 3-Pole, Single-Throw
- Fuji Type: SC-03
- Frame Size: 0A
- Frame Enclosure: Open Frame
- Auxillary Contacts : 1 Normally Open
- Power Consumption (In Rush): 95 VA
- Power Consumption (Sealed): 9 VA
- COIL VOLTAGE
- VAC: 200-220/200
- Hertz: 60/50
- LINE VOLTAGE
- Voltage: 110-120 (Single Phase)
- Horsepower: 1/3
- Full Load Amperage: 30
- SCCR: 25 kA
- Voltage: 110-120 (3-Phase)
- Horsepower: 1
- Full Load Amperage: 30
- SCCR: 25 kA
- Voltage: 200 (3-Phase)
- Horsepower: 2
- Full Load Amperage: 30
- SCCR: 25 kA
- Voltage: 220-240 (Single Phase)
- Horsepower: 1
- Full Load Amperage: 30
- SCCR: 25 kA
- Voltage: 220-240 (3-Phase)
- Horsepower: 2
- Full Load Amperage: 30
- SCCR: 25 kA
- Voltage: 440-480 (3-Phase)
- Horsepower: 5
- Full Load Amperage: 30
- SCCR: 10 kA
- Voltage: 550-600 (3-Phase)
- Horsepower: 5
- Full Load Amperage: 15
- SCCR: 5 kA
Country of Origin: Japan
Replaces Old Fuji Electric Part Numbers
- There are no older part numbers.
Other Part Numbers
SC-03Y, 35x60, M4, 30x48, 34x48~52, SC11ZA, 4NC0A0#10Y, F07170014m, 8022, Fuji Electric, Magnetic Contactor, Auxillary Relay
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
- SKU:
- 4NC0A0B10Y
- Condition:
- New
- Weight:
- 3.00 LBS
- Replaced by Part #:
- 4NC0A0B10
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
