Deltatherm 090-0402 Replacement Part
CALL (734) 326-3900 or SEND MESSAGE TO PARTS@TECHNICALHOTANDCOLD.COM FOR PRICE!
Includes:
- (1) - Mixing Valve Kit (090-0402)
- (1) 3-way Internal Thread Valve (06Z0143)
- (1) - Acuator AME 435(082H0161)
Specifications
- AME 435
- Length: 5"
- Width: 3"
- Height: 6-1/2"
- Supply Voltage: 24
- Hertz: 50/60
- Stroke 20mm
- Close Off Force 400N
- Actuator Speed: 7.5s/mm-15 s/mm
- Max. Medium Temperature: 120 (Celsius)
- Ambient Temp: 55 (Celsius)
- 065Z0143
- Manufacture: Danfoss
- Manufacture Model Number: VRB 3
- Manufacture Part Number: 065Z0143
- 3- Way Int. Thread Valve
- Shaft Diameter: 1/4"
- Shaft Length: 1"
- Inlet / Outlet Size: 3/4" RP Female
Country of Origin: Slovenia
Replaces Old Deltatherm Part Numbers
- There are no older part numbers.
Other Part Numbers
065Z0143, VRB 3, DN20, PN16, 082H0161, 5710104006284
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
- SKU:
- 090-0402
- Condition:
- New
- Weight:
- 10.00 LBS
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
