Carrier KGANP4601ALL Conversion Kit Natural Gas to Propane

1 reviews Write a Review
Brand
Carrier
SKU:
KGANP4601ALL
Condition:
New
Weight:
6.00 LBS
Replaced by Part #:
AGAGC8NPS01C

  • Technical Hot & Cold BBB Business Review

Carrier KGANP4601ALL Conversion Kit Natural Gas to Propane

  • Part Info & Specifications

  • Carrier KGANP4601ALL Replacement Part

    NOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # AGAGC8NPS01C

    Includes:

    • (7) - Main Burner Orifice (Drill Size 1.30mm) (323751-702)
    • (7) - Main Burner Orifice (Drill Size (1.25mm) (323269-703)
    • (7) - Main Burner Orifice (Drill Size No.54) (323269-701)
    • (7) - Main Burner Orifice (Drill Size No.55) (323269-704)
    • (7) - Main Burner Orifice (Drill Size No.56) (323272-702)
    • (1) - Diverter Plate (323184-301)
    • (1) - Low Gas Pressure Switch (Propane) (LGPS) (HK02LB008)
    • (1) - Nipple Size 1/8 MPT (CA52JZ103)
    • (1) - 90 Degree Street Elbow (1/8in / 3mm) (CA15RA001)
    • (1) - Male X Female X Female Tee (1/8in / 3mm) (CA21JZ001)
    • (1) - Splice Connector (1/4in Male to Male) (66175D55)
    • (2) - Splice Connector (3/16in Male to Male) (HY89SC047)
    • (1) - Orange Wire Assembly (18in / 457mm) (W182X23-04-018)
    • (1) - Orange Wire Assembly (12in / 305mm) (W182X66-04-012)
    • (1) - Yellow Wire Assembly (6in / 152mm) (W182Y66-11-006)
    • (1) - Yellow Wire Assembly (14in / 356mm) (W182Y66-11-014)
    • (1) - Yellow Wire Assembly (16in / 406mm) (W182Y66-23-016)
    • (1) - Wire Tie (HY76TB125)
    • (2) - Regulator Spring Kit (White-Propane-EF39ZW023) for White-Rodgers 36C, 36E, 36F, 36G, 36J Valve
    • (1) - Drill Bit Size 5/64" (328456-401)
    • (7) - Screws (327593-401)
    • (2) - Conversion Rating Plate Label - Non Condensing Furnaces (334263-204, 334263-207)
    • (2) - Conversion Rating Plate Label - Condensing Furnaces (334263-201, 334263-206)
    • (1) - Conversion Responsibility Label (334263-205)
    • (1) - Gas Control Conversion Label (adjusted) (334263-202)
    • (1) - Gas Control Conversion Label (converted)(334263-203)
    • (1) - Installation Instructions (AG-KGANP-04)

    Specifications

    • Natural Gas to Propane Conversion

    Replaces Old Carrier Part Numbers

    • KGANP4101ALL
    • KGANP2001ALL

    Other Part Numbers

    Replacement Components Division, Carrier Corporation, LH32DB210, LH32DB209, LH32DB203, LH32DB201, LH32DB206, 327593-401, 323184-301, HK02LB008, CA52JZ103, CA15RA001, CA21JZ001, 66175D55, HY89SC047, W182X23-04-018, W182X66-04-012, W182Y66-11-006, W182Y66-11-014, W182Y66-23-016, HY76TN125, 334263-204, 334263-207, 334263-201, 334263-206, 334263-205, 334263-202, 334263-203, AG-KGANP-04, 92-0659, 328456-401

    Fits Carrier, Bryant, Payne Models:

    (Press ctrl + F to find model number below.)

    310AAV024045AEJA, 310AAV024045AFJA, 310AAV024045AGJA, 310AAV024070AEJA, 310AAV024070AFJA, 310AAV024070AGJA, 310AAV036045AEJA, 310AAV036045AFJA, 310AAV036045AGJA, 310AAV036070AEJA, 310AAV036070AFJA, 310AAV036070AGJA, 310AAV036110AEJA, 310AAV036110AFJA, 310AAV036110AGJA, 310AAV042090AEJA, 310AAV042090AFJA, 310AAV042090AGJA, 310AAV048070AEJA, 310AAV048070AGJA, 310AAV048090AEJA, 310AAV048090AGJA, 310AAV048110AEJA, 310AAV048110AGJA, 310AAV048135AEJA, 310AAV048135AGJA, 310AAV060090AEJA, 310AAV060090AFJA, 310AAV060090AGJA, 310AAV060155AEJA, 310AAV060155AFJA, 310AAV060155AGJA, 310AAV066110AEJA, 310AAV066110AFJA, 310AAV066110AGJA, 310AAV066135AEJA, 310AAV066135AFJA, 310AAV066135AGJA, 310JAV024045AEJA, 310JAV024045AFJA, 310JAV024045AGJA, 310JAV024070AEJA, 310JAV024070AFJA, 310JAV024070AGJA, 310JAV036045AEJA, 310JAV036045AFJA, 310JAV036045AGJA, 310JAV036070AEJA, 310JAV036070AFJA, 310JAV036070AGJA, 310JAV036110AEJA, 310JAV036110AFJA, 310JAV036110AGJA, 310JAV042090AEJA, 310JAV042090AFJA, 310JAV042090AGJA, 310JAV048070AEJA, 310JAV048070AGJA, 310JAV048090AEJA, 310JAV048090AGJA, 310JAV048110AEJA, 310JAV048110AGJA, 310JAV048135AEJA, 310JAV048135AGJA, 310JAV060090AEJA, 310JAV060090AFJA, 310JAV060090AGJA, 310JAV060155AEJA, 310JAV060155AFJA, 310JAV060155AGJA, 310JAV066110AEJA, 310JAV066110AFJA, 310JAV066110AGJA, 310JAV066135AEJA, 310JAV066135AFJA, 310JAV066135AGJA, 311AAV024045AEJA, 311AAV024045AFJA, 311AAV024070AEJA, 311AAV024070AFJA, 311AAV036045AEJA, 311AAV036070AEJA, 311AAV036110AEJA, 311AAV042090AEJA, 311AAV048070AEJA, 311AAV048090AEJA, 311AAV048110AEJA, 311AAV048135AEJA, 311AAV060090AEJA, 311AAV060155AEJA, 311AAV066110AEJA, 311AAV066135AEJA, 311JAV024045AEJA, 311JAV024045AFJA, 311JAV024070AEJA, 311JAV024070AFJA, 311JAV036045AEJA, 311JAV036070AEJA, 311JAV036110AEJA, 311JAV042090AEJA, 311JAV048070AEJA, 311JAV048090AEJA, 311JAV048110AEJA, 311JAV048135AEJA, 311JAV060090AEJA, 311JAV060155AEJA, 311JAV066110AEJA, 311JAV066135AEJA, 312AAV024045AEJA, 312AAV024070AEJA, 312AAV036045AEJA, 312AAV036070AEJA, 312AAV036110AEJA, 312AAV042090AEJA, 312AAV048070AEJA, 312AAV048090AEJA, 312AAV048110AEJA, 312AAV048135AEJA, 312AAV060090AEJA, 312AAV060155AEJA, 312AAV066110AEJA, 312AAV066135AEJA, 312JAV024045AEJA, 312JAV024070AEJA, 312JAV036045AEJA, 312JAV036070AEJA, 312JAV036110AEJA, 312JAV042090AEJA, 312JAV048070AEJA, 312JAV048090AEJA, 312JAV048110AEJA, 312JAV048135AEJA, 312JAV060090AEJA, 312JAV060155AEJA, 312JAV066110AEJA, 312JAV066135AEJA, 313AAV024045AAJA, 313AAV024045ABJA, 313AAV024045ACJA, 313AAV048070AAJA, 313AAV048070ABJA, 313AAV048070ACJA, 313AAV048090AAJA, 313AAV048090ABJA, 313AAV048090ACJA, 313AAV060110AAJA, 313AAV060110ABJA, 313AAV060110ACJA, 313AAV060135AAJA, 313AAV060135ABJA, 313AAV060135ACJA, 313JAV024045AAJA, 313JAV024045ABJA, 313JAV024045ACJA, 313JAV048070AAJA, 313JAV048070ABJA, 313JAV048070ACJA, 313JAV048090AAJA, 313JAV048090ABJA, 313JAV048090ACJA, 313JAV060110AAJA, 313JAV060110ABJA, 313JAV060110ACJA, 313JAV060135AAJA, 313JAV060135ABJA, 313JAV060135ACJA, 315AAV036070AFJA, 315AAV036070AGJA, 315AAV048090AFJA, 315AAV048090AGJA, 315AAV060110AFJA, 315AAV060110AGJA, 315AAV066135AFJA, 315AAV066135AGJA, 315AAV066155AFJA, 315AAV066155AGJA, 315JAV036070AFJA, 315JAV036070AGJA, 315JAV048090AFJA, 315JAV048090AGJA, 315JAV060110AFJA, 315JAV060110AGJA, 315JAV066135AFJA, 315JAV066135AGJA, 315JAV066155AFJA, 315JAV066155AGJA, 340AAV024040ACSA, 340AAV024060ACSA, 340AAV036040ACSA, 340AAV036060ACSA, 340AAV036080ACSA, 340AAV048060ACSA, 340AAV048080ACSA, 340AAV048100ACSA, 340AAV060080ACSA, 340AAV060100ACSA, 340AAV060120ACSA, 340AAV060140ACSA, 350AAV024040FCSA, 350AAV024060FCSA, 350AAV036040FCSA, 350AAV036060FCSA, 350AAV036080FCSA, 350AAV048060FCSA, 350AAV048080FCSA, 350AAV048100FCSA, 350AAV060080FCSA, 350AAV060100FCSA, 350AAV060120FCSA, 350AAV060140FCSA, 353AAV036040FASA, 353AAV036040FBSA, 353AAV036060FASA, 353AAV036060FBSA, 353AAV036080FASA, 353AAV036080FBSA, 353AAV048080FASA, 353AAV048080FBSA, 353AAV060100FASA, 353AAV060100FBSA, 353AAV060120FASA, 353AAV060120FBSA, 355BAV042060ACSA, 355BAV042080ACSA, 355BAV060080ACSA, 355BAV060100ACSA, 355BAV060120ACSA, 58CTA045---14108, 58CTA045---14112, 58CTA070---14108, 58CTA070---14112, 58CTA070---14116, 58CTA090---14114, 58CTA090---14116, 58CTA090---14120, 58CTA110---14112, 58CTA110---14116, 58CTA110---14122, 58CTA135---14116, 58CTA135---14122, 58CTA155---14120, 58CTX045---14108, 58CTX045---14112, 58CTX070---14108, 58CTX070---14112, 58CTX070---14116, 58CTX090---14114, 58CTX090---14116, 58CTX090---14120, 58CTX110---14112, 58CTX110---14116, 58CTX110---14122, 58CTX135---14116, 58CTX135---14122, 58CTX155---14120, 58CVA070---15112, 58CVA070---16112, 58CVA090---15116, 58CVA090---16116, 58CVA110---15120, 58CVA110---16120, 58CVA135---15122, 58CVA135---16122, 58CVA155---15122, 58CVA155---16122, 58CVX070---15112, 58CVX070---16112, 58CVX090---15116, 58CVX090---16116, 58CVX110---15120, 58CVX110---16120, 58CVX135---15122, 58CVX135---16122, 58CVX155---15122, 58CVX155---16122, 58DLA045---14108, 58DLA045---14112, 58DLA045---15108, 58DLA070---14108, 58DLA070---14112, 58DLA070---14116, 58DLA070---15108, 58DLA090---14114, 58DLA090---14116, 58DLA090---14120, 58DLA110---14112, 58DLA110---14116, 58DLA110---14122, 58DLA135---14116, 58DLA135---14122, 58DLA155---14120, 58DLX045---14108, 58DLX045---14112, 58DLX045---15108, 58DLX070---14108, 58DLX070---14112, 58DLX070---14116, 58DLX070---15108, 58DLX090---14114, 58DLX090---14116, 58DLX090---14120, 58DLX110---14112, 58DLX110---14116, 58DLX110---14122, 58DLX135---14116, 58DLX135---14122, 58DLX155---14120, 58MCB040---12108, 58MCB040---12112, 58MCB060---12108, 58MCB060---12112, 58MCB060---12116, 58MCB080---12112, 58MCB080---12116, 58MCB080---12120, 58MCB100---12116, 58MCB100---12120, 58MCB120---12120, 58MCB140---12120, 58MEB040-F-10112, 58MEB040-F-11112, 58MEB060-F-10112, 58MEB060-F-11112, 58MEB080-F-10112, 58MEB080-F-10116, 58MEB080-F-11112, 58MEB080-F-11116, 58MEB100-F-10120, 58MEB100-F-11120, 58MEB120-F-10120, 58MEB120-F-11120, 58MXB040-F-12108, 58MXB040-F-12112, 58MXB060-F-12108, 58MXB060-F-12112, 58MXB060-F-12116, 58MXB080-F-12112, 58MXB080-F-12116, 58MXB080-F-12120, 58MXB100-F-12116, 58MXB100-F-12120, 58MXB120-F-12120, 58MXB140-F-12120, 58PHA045---11108, 58PHA045---10108, 58PHA045---12108, 58PHA070---11116, 58PHA070---10116, 58PHA070---12116, 58PHA090---11116, 58PHA090---10116, 58PHA090---12116, 58PHA110---11120, 58PHA110---10120, 58PHA110---12120, 58PHA135---11120, 58PHA135---10120, 58PHA135---12120, 58PHX045---11108, 58PHX045---10108, 58PHX045---12108, 58PHX070---11116, 58PHX070---10116, 58PHX070---12116, 58PHX090---11116, 58PHX090---10116, 58PHX090---12116, 58PHX110---11120, 58PHX110---10120, 58PHX110---12120, 58PHX135---11120, 58PHX135---10120, 58PHX135---12120, 58STA045---14108, 58STA045---14112, 58STA045---15108, 58STA045---15112, 58STA045---16108, 58STA045---16112, 58STA070---14108, 58STA070---14112, 58STA070---14116, 58STA070---15108, 58STA070---15112, 58STA070---16108, 58STA070---16112, 58STA070---16116, 58STA090---14114, 58STA090---14116, 58STA090---14120, 58STA090---15114, 58STA090---15120, 58STA090---16114, 58STA090---16116, 58STA090---16120, 58STA110---14112, 58STA110---14116, 58STA110---14122, 58STA110---15112, 58STA110---15122, 58STA110---16112, 58STA110---16116, 58STA110---16122, 58STA135---14116, 58STA135---14122, 58STA135---15122, 58STA135---16116, 58STA135---16122, 58STA155---14120, 58STA155---15120, 58STA155---16120, 58STX045---14108, 58STX045---14112, 58STX045---15108, 58STX045---15112, 58STX045---16108, 58STX045---16112, 58STX070---14108, 58STX070---14112, 58STX070---14116, 58STX070---15108, 58STX070---15112, 58STX070---16108, 58STX070---16112, 58STX070---16116, 58STX090---14114, 58STX090---14116, 58STX090---14120, 58STX090---15114, 58STX090---15120, 58STX090---16114, 58STX090---16116, 58STX090---16120, 58STX110---14112, 58STX110---14116, 58STX110---14122, 58STX110---15112, 58STX110---15122, 58STX110---16112, 58STX110---16116, 58STX110---16122, 58STX135---14116, 58STX135---14122, 58STX135---15122, 58STX135---16116, 58STX135---16122, 58STX155---14120, 58STX155---15120, 58STX155---16120, 58UVB060---12114, 58UVB080---12114, 58UVB080---12120, 58UVB100---12120, 58UVB120---12120, PG8JAA024045AEJA, PG8JAA024045AFJA, PG8JAA024045AGJA, PG8JAA024070AEJA, PG8JAA024070AFJA, PG8JAA024070AGJA, PG8JAA036045AEJA, PG8JAA036045AFJA, PG8JAA036045AGJA, PG8JAA036070AEJA, PG8JAA036070AFJA, PG8JAA036070AGJA, PG8JAA036110AEJA, PG8JAA036110AFJA, PG8JAA036110AGJA, PG8JAA042090AEJA, PG8JAA042090AFJA, PG8JAA042090AGJA, PG8JAA048070AEJA, PG8JAA048070AGJA, PG8JAA048090AEJA, PG8JAA048090AGJA, PG8JAA048110AEJA, PG8JAA048110AGJA, PG8JAA048135AEJA, PG8JAA048135AGJA, PG8JAA060090AEJA, PG8JAA060090AFJA, PG8JAA060090AGJA, PG8JAA060155AEJA, PG8JAA060155AFJA, PG8JAA060155AGJA, PG8JAA066110AEJA, PG8JAA066110AFJA, PG8JAA066110AGJA, PG8JAA066135AEJA, PG8JAA066135AFJA, PG8JAA066135AGJA, PG8JEA024045AAJA, PG8JEA024045ABJA, PG8JEA024045ACJA, PG8JEA048070AAJA, PG8JEA048070ABJA, PG8JEA048070ACJA, PG8JEA048090AAJA, PG8JEA048090ABJA, PG8JEA048090ACJA, PG8JEA060110AAJA, PG8JEA060110ABJA, PG8JEA060110ACJA, PG8JEA060135AAJA, PG8JEA060135ABJA, PG8JEA060135ACJA, PG8MAA024045AEJA, PG8MAA024045AFJA, PG8MAA024045AGJA, PG8MAA024070AEJA, PG8MAA024070AFJA, PG8MAA024070AGJA, PG8MAA036045AEJA, PG8MAA036045AGJA, PG8MAA036070AEJA, PG8MAA036070AGJA, PG8MAA036110AEJA, PG8MAA036110AGJA, PG8MAA042090AEJA, PG8MAA042090AFJA, PG8MAA042090AGJA, PG8MAA048070AEJA, PG8MAA048070AGJA, PG8MAA048090AEJA, PG8MAA048090AGJA, PG8MAA048110AEJA, PG8MAA048110AGJA, PG8MAA048135AEJA, PG8MAA048135AGJA, PG8MAA060090AEJA, PG8MAA060090AFJA, PG8MAA060090AGJA, PG8MAA060155AEJA, PG8MAA060155AFJA, PG8MAA060155AGJA, PG8MAA066110AEJA, PG8MAA066110AFJA, PG8MAA066110AGJA, PG8MAA066135AEJA, PG8MAA066135AFJA, PG8MAA066135AGJA, PG8MEA024045AAJA, PG8MEA024045ABJA, PG8MEA024045ACJA, PG8MEA048070AAJA, PG8MEA048070ABJA, PG8MEA048070ACJA, PG8MEA048090AAJA, PG8MEA048090ABJA, PG8MEA048090ACJA, PG8MEA060110AAJA, PG8MEA060110ABJA, PG8MEA060110ACJA, PG8MEA060135AAJA, PG8MEA060135ABJA, PG8MEA060135ACJA, PG9MAB024040ACSA, PG9MAB024060ACSA, PG9MAB036040ACSA, PG9MAB036060ACSA, PG9MAB036080ACSA, PG9MAB048060ACSA, PG9MAB048080ACSA, PG9MAB048100ACSA, PG9MAB060080ACSA, PG9MAB060100ACSA, PG9MAB060120ACSA, PG9MAB060140ACSA, PG9MXA036060AASA, PG9MXA036080AASA, PG9MXA048080AASA, PG9MXA060100AASA, PG9MXA060120AASA
