Carrier HK52EA123 ECM 3.0 Motor Module

Carrier HK52EA123 Replacement Part

Includes:

• (1) - ECM 3.0 Motor Module (Part Number: 8794707CYG09)
• (1) - Instruction Manual (Sheet Number: A-8794721JJ)
• (1) - Ring Adaptor
• (1) - 16 pin to 4 pin Adaptor
• (2) - 2.81 inch Clamp bolts
• (2) - 3.35 inch Clamp bolts

Specifications

• Manufacture: genteq
• ECM 3.0
• Phase: 1
• Frequency: 60
• Amperage: 12.8/7.4
• Horsepower: 1
• Voltage: 120/240

Note: Always check the blower wheel on your blower assembly. Bad or unbalanced blower wheels can cause premature motor failure due to vibration. If you are not sure what blower wheel fits your blower assembly, call us at 734-326-3900.

🚀 Note: The most common cause of ECM motor failure is poorly conditioned power. To protect sensitive ECM modules against transient voltage, power surges, lightning, and voltage spikes, it is highly recommended that you install a Zebra VZPRO inline ECM protector.

Note: Acceptable for use on: HD52RE120, HD52SE120, HD52RE122, and HD52SE122.

Replaces Old Carrier Part Numbers

• HK52EA120
• HK52EA122

Other Part Numbers

Replacement Components Division, Factory Authorized Parts, 0614, Carrier Corporation, Motor Module 1 HP< HK52AE123, 00822529324845, genteq, 8794707CYG09, HD52RE120, HD52SE120, HD52RE122, HD52SE122, GC07, ECM 3.0, E338178, 00D00L

Fits Carrier, Bryant, Payne Models:

(Press ctrl + F to find model number below.)

355BAV060080ACSA, 355BAV060100ACSA, 355BAV060120ACSA, 58UVB080---12120, 58UVB100---12120, 58UVB120---12120, 59MN7A060V211220, 59MN7A080V211220, 59MN7A100V211120, 59MN7A100V211222, 59MN7A120V241122, 59MN7A120V241222, 59TN6A080V211120, 59TN6A100V211120, 59TN6A100V211122, 59TN6A120V241122, 986TB60080V21A-A, 986TB66100V21A-A, 986TB66120V24A-A, 987MA60060V21A-B, 987MA60080V21A-B, 987MA60100V21A-A, 987MA66100V21A-B, 987MA66120V24A-A, 987MA66120V24A-B, PG9UAA060080AASA, PG9UAA060100AASA, PG9UAA060120AASA
