Carrier HD56JQ461 Replacement Part
Includes:
- (1) - ECM Axial Blower Motor (HD56JQ461)
Specifications
- Manufacturer Part #: TEK747D003002
- Voltage: 460
- Hertz: 50/60
- Number of Phases: 3
- Amps: 2.6
- RPM: 2530
- Rotation: CW
- Wattage: 1460
- Electronically Protected
- Continuous Air Over
Country of Origin: China
Note: Always check the blower wheel on your blower assembly. Bad or unbalanced blower wheels can cause premature motor failure due to vibration. If you are not sure what blower wheel fits your blower assembly, call us at 734-326-3900.
Note: Black (L1 50/60Hz) Yellow (L2 50/60Hz) Blue (L3 50/60Hz) Yellow/Green (PE) White (COM) Orange (+10VDC) Gray (0-10VDC/PWM)
Replaces Old Carrier Part Numbers
- HD56JZ461
Other Part Numbers
Factory Authorized Parts, Replacement Components Division, Carrier Corporation TEK747D003002,0 07 81897 06330 8, D2303202300011, E308134, Broad-Ocean,
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
48TC004004, 48TC002228
- SKU:
- HD56JQ461
- Condition:
- New
- Weight:
- 15.00 LBS
- Shipping:
- Calculated at Checkout
- Voltage:
- 460
- Amps:
- 2.6
- RPM:
- 2530
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
