Carrier HD46MQ133 ECM Blower Motor Assembly

Carrier HD46MQ133 Replacement Part

Includes:

• (1) - ECM Blower Motor Assembly (HD46MQ133)

Specifications

• Manufacturer: Zhongshan Broad-Ocean Motor Co., LTD.
• Model # ZWK702D0559801
• Horsepower: 3/4
• Voltage: 115-120
• Hertz: 50/60
• Amperage: 8.8
• Phase: Single
• RPM: 1050
• Frame: 48
• Electronically Protected
• Motor Duty/Cooling: Continuous Air Over
• Insulation Class: B
• Bearings: Ball
• Mount Type: Arm and Grommet
• Number of Mounts: 4
• Rotation: Counterclockwise Lead End
• Shaft Type: Single Side Flat Shaft
• Shaft Diameter: 1/2"
• Shaft Length: 3 15/16"

Country of Origin: China

Note: Always check the blower wheel on your blower assembly. Bad or unbalanced blower wheels can cause premature motor failure due to vibration. If you are not sure what blower wheel fits your blower assembly, call us at 734-326-3900.

Replaces Old Carrier Part Numbers

• HD46MQ126
• HD46MQ123

Other Part Numbers

MOTOR, BLOWER, HD46MQ133, HD 46MQ 133, Replacement Components Division, Carrier Corporation, Factory Authorized Parts, Broad-Ocean, 20170410, E308134

Fits Carrier, Bryant, Payne Models:

(Press ctrl + F to find model number below.)

PG95XAT42060BBAA, 925SA42060E17A-B, 59TP5A060E171214, 925TA42060E17A-B, 59SP5A060E171214, PG8JEA048090ACJA, 313AAV048090ACJA, 58PHA090 12116, PG8MEA048090ACJA, 313JAV048090ACJA, 58PHX090 12116
