Carrier 58MV660005 Replacement Part
Includes:
- (1) - ECM 3.0 Blower Motor Assembly (58MV660005)
- (1) - 4-pin to 16-pin Connector (-)
- (1) - Installation Instructions (99TA525033)
Specifications
- Manufacturer: Genteq
- Model # 5SME39SX L304B
- ECM Version: 3.0
- Horsepower: 1.0
- Voltage: 120/240
- Hertz: 60/50
- Amperage: 12.8/7.4
- Phase: Single
- RPM: 0-1300
- Electronic Protected
- Motor Duty/Cooling: Continuous Air Over
- Mounting: Wings
- Number of Wings: 4
- Rotation: Reversible
- Shaft Type: Single Side Flat Shaft
- Shaft Diameter: 1/2"
- Shaft Length: 3 15/16"
Note: Always check the blower wheel on your blower assembly. Bad or unbalanced blower wheels can cause premature motor failure due to vibration. If you are not sure what blower wheel fits your blower assembly, call us at 734-326-3900.
🚀 Note: The most common cause of ECM motor failure is poorly conditioned power. To protect sensitive ECM modules against transient voltage, power surges, lightning, and voltage spikes, it is highly recommended that you install a Zebra VZPRO inline ECM protector.
Replaces Old Carrier Part Numbers
- HD52SE122
- HD52SE120
Other Part Numbers
GC07, E338178, 15007VLR, HD52SE122, C229Y2080860, 2008242000081, 5SME39SX, L304B, 6348752, 6408502, 6423118, 5006744, 5592058, 5227704, 5306976, 6020667, 24X350089, D12V
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
315AAV060110AEJA, 315AAV060110AFJA, 315AAV060110AGJA, 315AAV066135AEJA, 315AAV066135AFJA, 315AAV066135AGJA, 315AAV066155AEJA, 315AAV066155AFJA, 315AAV066155AGJA, 315JAV060110AEJA, 315JAV060110AFJA, 315JAV060110AGJA, 315JAV066135AEJA, 315JAV066135AFJA, 315JAV066135AGJA, 315JAV066155AEJA, 315JAV066155AFJA, 315JAV066155AGJA, 58CVA110---15120, 58CVA110---14120, 58CVA110---16120, 58CVA135---15122, 58CVA135---14122, 58CVA135---16122, 58CVA155---15122, 58CVA155---14122, 58CVA155---16122, 58CVX110---15120, 58CVX110---14120, 58CVX110---16120, 58CVX135---15122, 58CVX135---14122, 58CVX135---16122, 58CVX155---15122, 58CVX155---14122, 58CVX155---16122, 59MN7A060V211220, 59MN7A080V211220, 59MN7A100V211120, 59MN7A100V211222, 59MN7A120V241122, 59MN7A120V241222, 59TN6A080V211120, 59TN6A100V211120, 59TN6A100V211122, 59TN6A120V241122, 986TB60080V21A-A, 986TB66100V21A-A, 986TB66120V24A-A, 987MA60060V21A-B, 987MA60080V21A-B, 987MA60100V21A-A, 987MA66100V21A-B, 987MA66120V24A-A, 987MA66120V24A-B, PG8JVA060110AAJA, PG8JVA066135AAJA, PG8MVA060110AAJA, PG8MVA066135AAJA
