Carrier 333147-751 Replacement Part
Includes:
- (1) - Gas Valve w/ Throttling Valve (333147-751)
- (1) - Installation Instructions (37-6829B)
Specifications
- Manufacturer: White-Rodgers
- Model # 36J55-50499
- Application: Direct Spark & Hot Surface Ignition
- Stages: 3
- Opening Speed: Slow
- Gas Type: Natural Gas or LP (Conversion Kit NOT Included)
- Voltage: 24
- Hertz: 50/60
- Amperage: 0.430
- BTU/HR @ 1" Pressure Drop: 140,000 (Natural); 226,800 (LP Gas)
- Regulator Water Column Set To: 3.5" High, 1.5" Medium
- Maximum Pressure: 1/2 PSI (14.0" W.C.)
- MEDIUM Regulator Adjustment Range (Natural): 1.0"-4.0"
- HIGH Regulator Adjustment Range (Natural): 2.0"-5.0"
- MEDIUM Regulator Adjustment Range (LP Gas): 4.5"-10.0"
- High Regulator Adjustment Range (LP Gas): 8.0"-12.0"
- Inlet: 1/2" NPT
- Outlet: 1/2" NPT
- Pressure Tap Size: 1/8" NPT
- Ambient Temperature Rating: -40° F to 175° F (-40° C to 79° C)
Replaces Old Carrier Part Numbers
- There are no older part numbers.
Other Part Numbers
6047718, 6604538, White Rodgers, 36J55 50499, E1, 1716, Rev A, 5001 5342, A108, 1717, A117, WR0094-5084, EF880W187, 0.280A, 24VAC, Valve Kit, 333147-751, 333147781, Factory Authorized Parts, Carrier Corporation, Replacement Components Division
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
355CAV042060FASA, 355CAV042080FASA, 355CAV060080FASA, 355CAV060100FASA, 355CAV060120FASA, 58MVC060-F-10114, 58MVC080-F-10114, 58MVC080-F-10120, 58MVC100-F-10120, 58MVC120-F-10120
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
