Burks 09CW10000350 Replacement Part
Includes:
- (1) - Pump (09CW10000350)
- (1) - Installation and Operation Manual (F0706D-Rev. H)
Specifications
- Manufacturer: US Motors
- Model # C55JXJN-4768
- Factory Wired for 115 Volts; 230 Volt Compatible
- Phase: Single
- Frame: 56J
- Thermally Protected
- Insulation Class: B
- Enclosure: Open Drip Proof
- Rotation: Counterclockwise Shaft End
- 60 HERTZ DATA
- Horsepower: 1/2
- Voltage: 115/208-230
- RPM: 3450
- Full Load Amperage: 8.2/4.2-4.1
- Service Factor: 1.6
- Service Factor Amperage: 10.8/5.9-5.4
- 50 HERTZ DATA
- Horsepower: 1/2
- Voltage: 110/220-230
- RPM: 2850
- Full Load Amperage: 9.8/4.9-5.2
- Service Factor: 1.0
- Service Factor Amperage: NA
Replaces Old Burks Part Numbers
- There are no older part numbers.
Other Part Numbers
Cat. No. EU0502, INS B, AMB40 C, PH 1, Code M, Duty Cont, Date Code L15C, Prot. Code 04420, 156060, IP 22, E22922, Nidec Motor Corporation, 23279, LM23279, C1795062, 5GA5N-1, Crane Pumps and Systems, 73749
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
