BKW BVS40502.70100 Replacement Part
This item must ship via freight. Please call us at 734-326-3900 to get a shipping quote.
Includes:
- (1) - Chiller (BVS40502.70100)
Specifications
- Dimension 1190x800x1320mm, Switch Cabinet Mounted Outside
- With Hermetic Compressor
- Refrigerant R134a - CDC-Free
- Cooling Capacity 14,5 kW at 18°C Water Inlet Temperature And Max. 30 Cooling Water Inlet Temperature
- Cooling Water Consumption 28 l/min At 10K Warming;
- Available Pressure Difference 6,0 Bar
- Cooling Water Regulation And Mud Collector Integrated;
- Piping Of Cooling Water Made Of VA/Ms
- 2-Pass Condenser Integrated
- Connection G3/4"
- Power Consumption In kW/A At 480 V:
- Compressor 6,04/15,0 Pump 0,74/1,8;
- Total 6,78/16,8;
- Water Tank Made Of PE, Volume 120 ltr.
- Level Control With:
- Level Sensor LK1022, Manufacturer IFM
- Centrifugal Pump CM1-6, Manufacturer Grundos
- Flow Rate 30l/min At 5,8 Bar
- Min Flow Rate > 15 l/min
- Piping Rubber Hose And Ms-Fittings 10 Bar
- Connections R3/4"- Male
- Operation With Appr. 35% Antifrogen N
- Control Unit E2017-ax-33
- With Main Switch
- Without Control Transformer 24VDC- By Customer
- Specification: PACCAR
- Switching Device: Siemens
- Clamps: Siemens 8WA1
- Connector : Harting
- Switch Cabinet Locking Via Main Switch Siemens With Max-Flex
- Fuse Holder Bussmann JTN
- Control Lamps "Push To Test" With LED
- Reclosing Lockout When Motor Protection Switch Is Activited
- Motor Protection Switch Siemens S0-Series
- With Terminal Block
- Color Of Wire/Clamps 24VDC: Orange
- Color Of Wire/Earth Terminals : Green/Yellow
- Wire End Ferrule IN 460V Circuit Without insulation Collars
- Temperature Controller:
- Electronic Two-Step Controller
- Hysteresis +/- 1,0k
- With Digital Must value/Actual Value Display IR33W
- Temperature Min Aalarm +5° C "Anti_Freeze Protection"
- 1x Potential Free Contact: Malfunction
- 1x Plug Connectors 6p/16A Feed-In "Start/Stop" 24VDC,
- And "Malfunction Advice"
- Voltage At A Frequency Of 60 Hz:
- Pump 369...528V;
- Compressor 414...506V;
- Control Voltage 24VDC: Operating Voltage 480V
- Separate Feed-In For Crank Case Heater 480/70W
Country of Origin: Germany
Replaces Old BKW Part Numbers
- There are no older part numbers.
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
- SKU:
- BVS40502.70100
- Condition:
- New
- Weight:
- 893.00 LBS
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
