BKW BVS40300.49200 Replacement Part
This item must ship via freight. Please call us at 734-326-3900 to get a shipping quote.
Includes:
- (1) - Water Chiller (BVS40300.49200)
Specifications
- Country of Origin: Germany
- Insertable Unit with Dimensions (1050x685x690mm)
- Hermetic Compressor
- Refrigerant: R407c (CFC Free)
- Cooling Capacity: 5.0kW @ 20°C Water Inlet Temperature and 35°C Water Inlet Temperature Max
- Consumption of Cooling Water: 20 l/min @ 5K Warming
- Available Pressure Difference Min 0.5 bar, Condenser Mechanically Cleanable
- Flow Regulator for Cooling Water and Dirt Deflector Integrated, Connection G 3/4" Female
- Power Consumption in kW/A @ 480 V: Compressor 1.8/4.2; Pump 1.0/2.05; Total 2.8/6.25
- Water Tank Made of PE 65 ltr.
- Flow Control with Liquid Level Sensor made by IFM LI5142
- Immersion Pump PSR0406
- Flow Rate: 35 l/min @ 7.0 bar
- Min Flow Rate > 10 l/min
- Flow Regulation with Flow Sensor SI5010
- Piping Rubber Hose and Ms-Fittings 10 bar
- Connections Outlet G1"; Inlet G1"
- Cooling with Approximately 35% Antifrogen N
- Control Unit E2009-FI-03 without Main Switch and Transformer
- Switching Devices: Siemens
- Clamps: Weidmuller EDU-Series
- Connectors: Harting
- Switch Cabinet Lock: Rittal SZ2418.000 (24 VDC)
- AWG Wiring
- Conductor Marking with Brady-Label
- Switch Lock at Alarm of Motor Protection Switch and Pressure Control Switch
- Cutout for Magnetic Valve
- Temperature Controller: Up to 20°C No Cooling
- Difference Control Within the Range of 20°C to 28°C
- From 28°C Fixed Value Cooling to 28°C
- Hysteresis +/- 0.2K
- Digital Actual Valve Must Value Display IR32W
- Limit Value Min 10°C/35°C
- 1x Temperature Clamp Sensor d=11mm for Reference Value on 10m Cable
- Precision Regulation for Continuous Operation of Compressor and Hot Gas Bypass Temperature Sensor at Inlet
- 5x Potential Free Contact: Flow Level/Flow Rate/Temperature/Cooling Circuit/External Water Supply
- Voltage @ Frequencty of 60 Hz: Fan/Pump 277/480V; IP54
- Compressor: ---/480V; IP33
- Control Voltage: 24VDC, Operating Voltage @ 460V
- Labeling in German/English
- Connections for Cooling Water: 3/4"
Replaces Old BKW Part Numbers
- There are no older part numbers.
Other Part Numbers
BKW, ERK09W/ZR22-Pr-PXK0405/R407c/DDC, BVS40300.49200, Chiller, Cooler, Water
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
- SKU:
- BVS40300.49200
- Condition:
- New
- Weight:
- 151.00 LBS
