BKW BV1.100040360 Replacement Part
This item must ship via freight. Please call us at 734-326-3900 to get a shipping quote.
Includes:
- (1) - Chiller (BV1100040360)
Specifications
- Continuous Reccoling Unit DL16/4V-4492Y-1KKZPR
- Dimensions: 465x345x1330mm with Base 300x465mm
- Hermetic Compressor
- Refrigerant: R134A - CFC Free
- POWER INPUT IN kW/A @ 460V
- Compressor: 1.10/2.8
- Fan: 0.07/0.17
- Pump: 0.42/1.13
- Total: 1.59/4.1
- VOLTAGE (60Hz):
- Compressor: 460
- Control: 24 DC
- Operating Voltage: 460
- Cooling Capacity: 1.85 kW @ 27°C Ambient Temperature
- Max Ambient Temperature: 45°C
- Ambient Temperature Range: 10°C to 45°C
- Medium Temperaure: 24/20°C, Viscosity 120 mm²/s
- Flowrate: 13 l/m; Pressure Loss 0.5 bar
- Evaporator Welded Coiled Tube of Copper, Shell ST.35; Max Pressure 16 bar
- Pump with Electronic Ignition Like R+I Flow Sheet K6/8
- Pump KF8 RF1-D15 Flow Rate: 12 l/min @ <10 bar
- Piping Rubber Hose, Brass and Steel Zinced
- Connections: R3/4" - Female with Closing Plug R3/4"
- At Air Inlet: Metal Filter 2000-98-04a, 328mmx240mmx3mm
- Control E1830-AJ-63; Without Main Switch, Control Lamps and Control Transformer
- Pump Connection and Power Supply on Clamps
- Signal Exchange with Harting 24-Pole
- Temperature Control
- Difference Controller Type IR32W
- Range: -20 to 20K; Hysteresis +/-1K
- Temperature Max: 40°C
- Sensor on 5m Cable Signal Exchange with Harting 24-Pole
- Labels in German/English
Replaces Old BKW Part Numbers
- There are no older part numbers.
Other Part Numbers
BV1.100040360, BKW, BV1100040360, Chiller, R134a, 460V
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
