Allied Armstrong R43110-002 Ignition Module

Allied Armstrong R43110-002 Replacement Part

Includes:

• (1) - Ignition Module (-)
• (1) - Ignition Wire (-)
• (3) - Wire Diagram Stickers (-)
• (1) - Instructions (-)

Specifications

• Manufacturer: Fenwal
• Model # 35-615900-227
• Automatic Ignition System
• Pre-Purge: 30 Seconds, Ignition: 15 Seconds
• Interpurge: 30 Seconds
• Input: 24 VAC, 50/60 Hz, 300 mA
• Valve: 24 VAC, 2.0 A Maximum
• Inducer: 120 VAC, 3.0 A or 240 VAC, 1.5 A, 1/4 HP
• Ambient: -40° F to 160° F

Replaces Old Allied Armstrong Part Numbers

• R43110-001
• R43107-001
• R41865-001
• R41582-002
• R41582-001
• R39048B001

Other Part Numbers

35-615800-227, R43110-002, Fenwal, 35-615900-227, ANSI Z21.20, CAN/CSA-C22.2, 199-M89, 1008CB

Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:

(Press ctrl + F to find model number below.)

100GHC36A-1, 100GHC36B-1, 100GHC36B-26HW, 100GHC36B-1, 26HWC122A-10, 26HWC122LA-10, 26HWC122LA-38HW, 26HWC122LA-1, 38HWC182A-11, 38HWC242A-10, 38HWC242A-11, 38HWC242LA-10, 38HWC242LA-11, 38HWC242LA-51HW, 38HWC242LA-1, 51HWC182A-9, 51HWC182LA-9, 51HWC242A-9, 51HWC242LA-9, 51HWC302A-9, 51HWC302LA-9, 60GHC24A-1, 60GHC30A-1, 60GHC36A-1, 60GHC36B-1, 60GHC36B-64HW, 60GHC36B-1, 64HWC182A-9, 64HWC182LA-9, 64HWC242A-9, 64HWC242LA-9, 64HWC302A-9, 64HWC302LA-9, 80GHC24A-1, 80GHC30A-1, 80GHC36A-1, 80GHC36B-1
