AC Fan Motor

ICP 34329502 Replacement PartIncludes:(1) - Fan Motor (34329502)SpecificationsManufacturer: US MotorsModel # K55HXMMC-4297Horsepower: 1/6Voltage: 208/230Hertz: 60Amperage: 1.10Phase: SingleRPM: 825Speeds: SingleFrame: 48YThermally ProtectedInsulation...

ICP 96799 Replacement PartIncludes:(1) - Fan Motor (96799)SpecificationsManufacturer: US MotorsModel # KA55HXHJG-4614Horsepower: 1/4Voltage: 230Hertz: 60Amperage: 2.0Phase: SingleRPM: 980Speeds: 1Frame: 48YThermally ProtectedInsulation Class: AMotor...

ICP F257-3468 Replacement PartIncludes:(1) - MOTOR MULTI HP CONDENSER MOTOR 1/5-1/2HP 208/230V 1075RPM 2SPD 10/12.5/370 CAPACITOR PER HP REQUIRED (F257-3468)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause...

ICP F257-3728 Replacement PartIncludes:(1) - MOTOR CONDENSER 1/4 HP 208/230V 1075RPM 5/370 CAPACITOR REQUIRED (F257-3728)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to...

Lennox 13H36 Replacement PartIncludes:(1) - Fan Motor (13H36)SpecificationsManufacturer: US Motors Model # K55HXLCK-3613Horsepower: 1/4BVoltage: 208-230Hertz: 60Amperage: 2.0Phase: SingleRPM: 825Frame: 48YThermally ProtectedEnclosure: TEAOMotor...

Lennox 19L25 Replacement PartIncludes:(1) - Condenser Fan Motor (19L25)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to vibration. If you are not sure what fan blade fits your...

Lennox 19U98 Replacement PartIncludes:(1) - Motor (19U98)SpecificationsManufacturer: GenteqManufacturer Part #: 5SME39HLHF359Horsepower: 1/3Voltage: 240 Hertz: 60Number of Phases: 1Amps: 2.80Rotation: CCW Lead EndShaft Diameter: 1/2"Shaft Length:...

Lennox 25G22 Replacement PartIncludes:(1) - Fan Motor (25G22)SpecificationsManufacturer: US MotorsModel # KA55HXGMR-7873Horsepower: 1/2Voltage: 208-230Hertz: 60Amperage: 2.80Phase: SingleRPM: 1075Speeds: 1Frame: 48YThermally ProtectedMotor Cooling/Duty:...

Lennox 27H45 Replacement PartIncludes:(1) - Fan Motor (27H45)SpecificationsManufacturer: US Motors Model Number: K55HXLCH-3611 Horsepower: 1/6Voltage: 208-230Hertz: 60Amperage: 1.1Phase: SingleRPM: 1075Frame: 48YThermally ProtectedMotor Cooling/Duty: Air...

Lennox 27J07 Replacement PartIncludes:(1) - Fan Motor (27J07)SpecificationsManufacturer: US MotorsModel Number: K55HXBPH-6161Horsepower: 1/2Voltage: 460Hertz: 60Amperage: 1.4Phase: SingleRPM: 1075Frame: 48YThermally ProtectedMotor Cooling/Type: Air Over...

Lennox 29M86 Replacement PartIncludes:(1) - Fan Motor (29M86)SpecificationsManufacturer: US Motor Manufacturer Part #: K55HXJWW-9337Horsepower: 1/2Voltage: 460 Hertz: 60Number of Phases: 1Amps: 1.8RPM: 1075Number of Speeds: 3Rotation: CCW Lead End Frame:...

Lennox 36A75 Replacement PartIncludes:(1) - Fan Motor (36A75)SpecificationsManufacturer: US MotorsManufacturer Part # K55HXMGM-6379Brake Horsepower: 1/3Voltage: 208-230Hertz: 60Amperage: 2.0Phase: SingleRPM: 1075Speeds: 2Frame: 48YThermally...

Lennox 46K88 Replacement PartIncludes:(1) - Fan Motor (46K88)SpecificationsManufacturer: US MotorsModel # K55HXKPR-9736Horsepower: 1/4Voltage: 208-230Hertz: 60Amperage: 1.8Phase: SingleRPM: 1075Speeds: 1Frame: 48YThermally ProtectedInsulation Class:...

Lennox 65G60 Replacement PartIncludes:(1) - Fan Motor (65G60)SpecificationsManufacturer: InterLinkModel # Y7S862B521Horsepower: 1/6Voltage: 208-230Hertz: 60Full Load Amperage: 1.10Phase: SingleRPM: 825Speeds: 1Frame: 48YThermally ProtectedMotor...

Lennox 68J25 Replacement PartIncludes:(1) - Fan Motor (68J25)SpecificationsManufacturer: US Motors Manufacturer Part #: K55HXDBW-6757Horsepower: 1/3Voltage: 460 Hertz: 60Number of Phases: 1Amps: 0.82RPM: 1075Number of Speeds: 1Rotation: CCW Lead...

Lennox 72L06 Replacement PartIncludes:(1) - Condenser Fan Motor (72L06)SpecificationsHorsepower: 1/4Voltage: 208-230 Number of Phases: 1RPM: 1075Shaft Length: 2"Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause...

Lennox 76N19 Replacement PartIncludes:(1) - Condenser Fan Motor (76N19)SpecificationsManufacturer: RescueManufacturer Part #: 5462Horsepower: 1/3-1/6Voltage: 208-230 Hertz: 60Number of Phases: 1Amps: 1.8/2.6RPM: 1075Number of Speeds: 2Rotation: REVFrame:...

Lennox 91X16 Replacement PartIncludes:(1) - Condenser Fan Motor (91X16)SpecificationsHorsepower: 1/3-1/5Voltage: 208-230 Hertz: 60Number of Phases: 1Amps: 2.4RPM: 825Shaft Length: 6"Bearing Type: SleeveNote: Always check the fan blade on your fan...

Includes:(1) - Condenser Fan Motor (Y3975)Specifications:Voltage: 310 Number of Phases: 1RPM: 860Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to vibration. If you are not sure...

Lennox Y4635 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 19L24Includes:(1) - Condenser Fan Motor (Y4635)SpecificationsHorsepower: 1/4Voltage: 208/230 Hertz: 60Number of Phases: 1Amps: 1.5RPM: 825Number of...

Lennox Y4644 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 19L41Includes:(1) - Condenser Fan Motor (Y4644)SpecificationsHorsepower: 1/3-1/6Voltage: 208/230 Hertz: 60Number of Phases: 1Amps: 1.5/2.8RPM: 1075Number...

Lennox Y4645 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 19L42Includes:(1) - Condenser Fan Motor (Y4645)SpecificationsHorsepower: 1/3-1/6Voltage: 208/230 Hertz: 60Number of Phases: 1Amps: 1.2/1.9RPM: 825Number...

Lennox Y5434 Replacement PartIncludes:(1) - Fan Motor (Y5434)SpecificationsManufacturer: Asynchronism Manufacturer Part #: KBR0059A20010624775Voltage: 115 Hertz: 60Number of Phases: 3Amps: 0.40Shaft Length: 2" Width: 1/4"Note: Always check the fan blade...

Mitsubishi Electric Corporation CMA-1 Replacement PartIncludes:(1) - CONDENSATE MANAGEMENT KIT FOR MULTI-POSITION AIR HANDLERS (CMA-1)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure...

Mitsubishi Electric Corporation E02897302 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # E12897302Includes:(1) - Line Flow Fan (E02897302)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan...

Mitsubishi Electric Corporation E12C32302 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # E22C32302Includes:(1) - Line Flow Fan (E12C32302)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan...

Mitsubishi Electric Corporation E12F28302 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # E22F28302Includes:(1) - LINE FLOW FAN (E12F28302)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan...

Mitsubishi Electric Corporation QSMS1201M Replacement PartIncludes:(1) - 12"" SINGLE FAN STAND COLOR (QSMS1201M)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to vibration. If you...

Mitsubishi Electric Corporation T2WE93301 Replacement PartIncludes:(1) - CONDENSER FAN MOTOR (MUZ09UN) (T2WE93301)Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to vibration. If...

Reznor 147104 Replacement PartNOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # 196826Includes:(1) - MotorNote: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to...
